Type

C BX

C BXE

CBXE24

CBXT

CBXET

CBXK

CBXEK

Protection rating

IP54

IP54

IP54

IP54

IP54

IP54

IP54

Power Supply(V)

230

230

230

230

230

230

230

Motor power Supply(V)

24 DC

230 AC

230 AC

230 AC

230 AC

230 AC

230 AC

Current draw (A)

3

3

9 MAX

2.5

2.5

3.5

3.5

Power(W)

450

450

240

780

780

750

750

Duty cycle (%)

30

30

50

50

50

30

30

Traction force(Nm)

60

60

25

80

80

120

120

Motor’s thermo-protection

150

150

-

150

150

150

150

Operating Temperature

-20  -  + 55

-20  -  +55

-20  -  + 55

-20  -  +55

-20  -  + 55

-20  -  +55

-20  -  + 55

Max weight of Gate leaf

300kg

800kg

400kg

Type

TOP

Maximum Leaf  withds

(mm)

800 - 1400

Header  Cross – Section

(H x D)

120 X 250 (mm)

Maximum Leaf Weihgts

2 x 80kg (Two Leaves)

Opening Speed

60 – 160cm/s (One Leaf)

Power  Supply

230V/50Hz
