TECHNICAL FEATURES
|
Type |
C BX |
C BXE |
CBXE24 |
CBXT |
CBXET |
CBXK |
CBXEK |
|
Protection rating |
IP54 |
IP54 |
IP54 |
IP54 |
IP54 |
IP54 |
IP54 |
|
Power Supply(V) |
230 |
230 |
230 |
230 |
230 |
230 |
230 |
|
Motor power Supply(V) |
24 DC |
230 AC |
230 AC |
230 AC |
230 AC |
230 AC |
230 AC |
|
Current draw (A) |
3 |
3 |
9 MAX |
2.5 |
2.5 |
3.5 |
3.5 |
|
Power(W) |
450 |
450 |
240 |
780 |
780 |
750 |
750 |
|
Duty cycle (%) |
30 |
30 |
50 |
50 |
50 |
30 |
30 |
|
Traction force(Nm) |
60 |
60 |
25 |
80 |
80 |
120 |
120 |
|
Motor’s thermo-protection |
150 |
150 |
- |
150 |
150 |
150 |
150 |
|
Operating Temperature |
-20 - + 55 |
-20 - +55 |
-20 - + 55 |
-20 - +55 |
-20 - + 55 |
-20 - +55 |
-20 - + 55 |
|
Max weight of Gate leaf |
300kg |
800kg |
400kg |
